IButton DS1922E Thermochron Data Logger (+15 To +140°C)
Model DS1922E
£177.00(£212.40 incl. VAT)
More iButton Temperature options
In stock · 5–10 working days delivery
Free Delivery UK orders over £500
Money Back Guarantee · 100% refund
UK Company
Based in Newbury
40 Years Experience
Measys Group Ltd
Expert Engineers
Talk to our engineers
ModelDS1922E
TypeiButton Temperature
Delivery5–10 working days
How it works
From logger to data in three steps
Place the iButton, it records on its own, then download the readings with a USB adapter and software.
Place the logger
Attach the iButton to the goods, vehicle or location you need to monitor.
It records automatically
Measures temperature or humidity and stores thousands of readings in memory.
Download the data
Connect via USB adapter and software to view, graph and export the log.
*USB adapter, cable and software required
Description
The DS1922E iButton® temperature logger is a rugged, self-sufficient system that measures temperature and records the result in a protected memory section. A total of 8192 8-bit readings or 4096 16-bit readings can be stored at recording intervals ranging from 1s to 273hrs. In addition to this, there are 512 bytes of SRAM for storing application-specific information and 64 bytes for calibration data.
A mission to collect data can be programmed to begin immediately, or after a user-defined delay or after a temperature alarm. Access to the memory and control functions can be password protected. The DS1922E is configured and communicates with a host computing device through the serial 1-Wire® protocol, which requires only a single data lead and a ground return. Every DS1922E is factory-lasered with a guaranteed unique 64-bit registration number that allows for absolute traceability. The durable stainless-steel package is highly resistant to environmental hazards such as dirt, moisture, and shock. Accessories permit the DS1922E to be mounted on almost any object, including containers, pallets, and bags.
NOTE: Requires Software and adapter cable to communicate.
Features
- Automatically Wakes Up, Measures Temperature, and Stores Values in 8KB of Data-Log Memory in 8- or 16-Bit Format
- Digital Thermometer Measures Temperature with 8-Bit (0.5°C) or 11-Bit (0.0625°C) Resolution
- Temperature Accuracy: ±1.5°C from +110°C to +140°C, ±7°C typical from +15°C to +110°C
- Water Resistant (IP56) or Waterproof (to IP68) if placed inside DS9107i Button Capsule (Exceeds Water Resistant 3 ATM Requirements)
- Sampling Rate from 1s Up to 273hr
- Programmable High and Low Trip Points for Temperature Alarms
- Programmable Recording Start Delay After Elapsed Time or Upon a Temperature Alarm Trip Point
- Quick Access to Alarmed Devices Through 1-Wire Conditional Search Function
- 576 Bytes of General-Purpose Memory
- Two-Level Password Protection of All Memory and Configuration Registers
- Communicates to Host with a Single Digital Signal Up to 15.4kbps at Standard Speed or Up to 125kbps in Overdrive Mode Using 1-Wire Protocol
- Operating Temperature Range: +15°C to +140°C
Specifications
- Memory Type: NVSRAM
- Memory Size512 bytes
- Data Logger Size8192 byte
- Data Logger Sample Rate1s to 273 hours
- Data Logger Accuracycorrectible to +/- 0.5’C
- Data Logger ResolutionSelectable
8-bit = 0.5’C
11-bit = 0.0625’C - Measurement Range+15 to +140’C
- Thermal Response timeup to 130 seconds
- Security Featurespassword protected
- Programmable AlarmTemperature High/Low
- Real Time ClockYes
- RTC Accuracydepends on temperature, @ 20’C drift ~ 1 minute/month.
- Weight3.3g
- Sizediameter 17.35 x 5.9mm
- IP RatingIP56
- Battery Lifedepends on number of factors such as Temperature and Logging rate. E.g. 8-bit logging @ 20’C at 30 second intervals, the battery should last around 300 days. Record every 10 minutes in 8-bit mode @ 20’C, the battery should last around 5.5 years.
Technical
Applications
- Stand-alone high-temperature measuring and logging applications
- Steam sterilization applications
Description
The DS1922E iButton® temperature logger is a rugged, self-sufficient system that measures temperature and records the result in a protected memory section. A total of 8192 8-bit readings or 4096 16-bit readings can be stored at recording intervals ranging from 1s to 273hrs. In addition to this, there are 512 bytes of SRAM for storing application-specific information and 64 bytes for calibration data.
A mission to collect data can be programmed to begin immediately, or after a user-defined delay or after a temperature alarm. Access to the memory and control functions can be password protected. The DS1922E is configured and communicates with a host computing device through the serial 1-Wire® protocol, which requires only a single data lead and a ground return. Every DS1922E is factory-lasered with a guaranteed unique 64-bit registration number that allows for absolute traceability. The durable stainless-steel package is highly resistant to environmental hazards such as dirt, moisture, and shock. Accessories permit the DS1922E to be mounted on almost any object, including containers, pallets, and bags.
NOTE: Requires Software and adapter cable to communicate.
Features
- Automatically Wakes Up, Measures Temperature, and Stores Values in 8KB of Data-Log Memory in 8- or 16-Bit Format
- Digital Thermometer Measures Temperature with 8-Bit (0.5°C) or 11-Bit (0.0625°C) Resolution
- Temperature Accuracy: ±1.5°C from +110°C to +140°C, ±7°C typical from +15°C to +110°C
- Water Resistant (IP56) or Waterproof (to IP68) if placed inside DS9107i Button Capsule (Exceeds Water Resistant 3 ATM Requirements)
- Sampling Rate from 1s Up to 273hr
- Programmable High and Low Trip Points for Temperature Alarms
- Programmable Recording Start Delay After Elapsed Time or Upon a Temperature Alarm Trip Point
- Quick Access to Alarmed Devices Through 1-Wire Conditional Search Function
- 576 Bytes of General-Purpose Memory
- Two-Level Password Protection of All Memory and Configuration Registers
- Communicates to Host with a Single Digital Signal Up to 15.4kbps at Standard Speed or Up to 125kbps in Overdrive Mode Using 1-Wire Protocol
- Operating Temperature Range: +15°C to +140°C
Specifications
- Memory Type: NVSRAM
- Memory Size512 bytes
- Data Logger Size8192 byte
- Data Logger Sample Rate1s to 273 hours
- Data Logger Accuracycorrectible to +/- 0.5’C
- Data Logger ResolutionSelectable
8-bit = 0.5’C
11-bit = 0.0625’C - Measurement Range+15 to +140’C
- Thermal Response timeup to 130 seconds
- Security Featurespassword protected
- Programmable AlarmTemperature High/Low
- Real Time ClockYes
- RTC Accuracydepends on temperature, @ 20’C drift ~ 1 minute/month.
- Weight3.3g
- Sizediameter 17.35 x 5.9mm
- IP RatingIP56
- Battery Lifedepends on number of factors such as Temperature and Logging rate. E.g. 8-bit logging @ 20’C at 30 second intervals, the battery should last around 300 days. Record every 10 minutes in 8-bit mode @ 20’C, the battery should last around 5.5 years.
Technical
Applications
- Stand-alone high-temperature measuring and logging applications
- Steam sterilization applications
